igus® smart plastics
CF.P¶
Mechanical Specifications¶
Technical Data:
| Accuracy class |
G |
|
|---|---|---|
| Combined error |
% of rated load |
0.020 |
| Creep error / DR (30 min.) |
% of rated load |
0.017 |
| Temperature coefficient characteristic value |
%/10 °C |
0.012 |
| Temperature coefficient zero point |
%/10 °C |
0.040 |
| Rated temperature range |
°C |
-10 … +40 |
| Operating temperature range |
°C |
-30 … +70 |
| Rated deflection |
mm |
~0.4 |
| Overload range |
% of rated load |
150 |
| Limit load |
% of rated load |
200 |
| Breaking load |
% of rated load |
300 |
| Cable length |
m |
3 |
| Material |
Stainless steel – 1.4548 |
|
| Protection class |
IP67 |
|
| Rated load |
kg |
1,000 |
Electrical Specifications
| Rated output (RO) |
mV/V |
2.00 |
|---|---|---|
| Rated output tolerance |
% |
± 0.1 |
| Input resistance |
Ω |
400 ±20 |
| Output resistance |
Ω |
350 ±3 |
| Recommended supply voltage |
V |
5 … 10 |
| Connector |
none or Harting HAN 3A |
Order Information
| IS.ZB.WZ.01.01.0 |
Load cell 1t assembled |
|---|---|
| MAT0090328 |
Load cell 1t unassembled |
| IS.ZB.WZ.02.01.0 |
Load cell 2t assembled |
| MAT0090870 |
Load cell 2t unassembled |
